DIGITAL TWIN / GEORADAR
& REVERSE ENGINEERING
See the potential offered by EB Team
List of services
-
Field Surveys - Digital Twin Create an engaging, guided experience using captions to tell a story about your space. Add tags to draw the viewer's attention to key points of interest. As-Is Reality: The Digital Twin allows the user to digitally navigate the captured space, take measurements, and enter information (technical attachments, videos, photos, etc.). It eliminates the need for additional site visits and can be shared with the team or client via a link.Voce di elenco 1
-
Adapt the data you share with different groupsVoce di elenco 2
Organizza, condividi e mostra facilmente i dati contenuti nel tuo space con gruppi diversi creando una vista unica per ogni pubblico.
-
Crea e condividi file as-built con applicazioni di terze parti With EB Team's BIM files and AutoDesk Revit integration, companies can order complete as-built designs. The technology provides point clouds of the surveyed areas in both .xyz and E57 (high point density) formats, allowing users to use them for any type of processing. CAD files: Survey CAD files processed according to the ISO 13567 standard can also be requested. BIM files: LOD 200 BIM files in .rtv and .dwg formats for interiors and exteriors.Voce di elenco 3
-
Integrazione con Autodesk Construction Cloud Collaborate on projects more efficiently with the visual site context provided by digital twins. Revolutionize traditional RFI processes with synchronized RFIs from digital twins. You can now place an Autodesk RFI marker in the area of interest to allow all project stakeholders to view the RFI in its context within the site.Voce di elenco 4
-
Get 2D floor plans in 2 daysSave time, money, and effort with ready-to-use floor plans, available in 2 business days in PNG, PDF, and SVG formats. .png and .svg floor plans: automatically display the layout of the acquired space via .png and .svg files, providing the user with all the documentation ready for their project. Within the files, the spaces are already divided, labeled, and contain the relevant measurements.
-
Sblocca gli approfondimenti basati sull'intelligenza artificiale in grado di accelerare la tua attivitàArtificial intelligence analyzes any property or portfolio at scale to generate insights tailored to your business needs. Answer any question about your building, from accessibility to property condition, and use them to improve business operations, customer experience, and much more.
-
Methodology and ground penetrating radar (GPR) instrumentation used
In funzione delle caratteristiche di accessibilità ai luoghi e delle condizioni, morfologia e dimensioni delle aree da investigare oltre che delle condizioni del terreno, si propone l’impiego della seguente strumentazione georadar: Stream UP, georadar di ultima generazione prodotto da IDS Spa.
Stream UP è un sistema GPR multicanale, multifrequenza, a doppia polarizzazione dedicato alla mappatura completa del sottosuolo per la ricerca di strutture interrate, cavità, sottoservizi, distribuzione dell’umidità, ecc.. progettato per l’acquisizione su aree estese con acquisizione in copertura totale.
Stream UP è un innovativo sistema GPR in grado di operare a velocità di acquisizione fino a 60 km/h e risulta, pertanto, ideale per rilievi in contesto urbano aperto al traffico.
Il sistema viene trainato da un normale mezzo dotato di gancio di traino (Quad, automobile, minicar, furgone, auto mezzo elettrico, ecc..) e può essere trasportato anche sullo stesso veicolo utilizzato per l'acquisizione grazie alle ridotte dimensioni.
-
Positioning systemsStream UP is able to manage position information from DGPS (Leica GS18) or Robotic Total Station (Leica TS50) so as to efficiently manage the results even on GIS systems. Furthermore, the Stream UP proposed for the survey in question is equipped with an inertial motion station (APS – IMU) for DGPS positioning in the absence of an RTK signal. This allows maximum DGPS precision to be maintained even along road sections where the GNSS signal is poor due to the presence of trees, buildings, vertical obstacles of various kinds, etc., as is possible in acquisitions in mountainous contexts such as the one in question. GPS data can be saved in absolute coordinates and the IQMaps processing software can read the same coordinates automatically. The Stream C system is compatible with GPS according to the NMEA standard.
-
PerformanceFrom a technical standpoint, this instrumentation is equipped with a 200 MHz antenna array (19 channels) in VV polarization and a second array (19 channels) in HH polarization, thus combining maximum exploration depth with maximum resolution in a single pass in FULL COVERAGE. This mode allows for complete mapping of the investigated area without leaving unexplored portions (unlike what happens with the use of the traditional single-antenna system) with the aid of specific real-time navigation software. The instrumentation used is mounted on a special trolley equipped with an echo Doppler device for measuring the distances traveled and a support for a DGPS antenna or prism.
